Intel? Xeon? Processor E3-1505M v6
(8M Cache, 3.00 GHz)
Intel Xeon E3-1505MV6. Processor family: Intel? Xeon? E3 v6, Processor socket: FCBGA1440, Processor lithography: 14 nm. Memory channels: Dual-channel, Maximum internal memory supported by processor: 64 GB, Memory types supported by processor: DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM. On-board graphics card model: Intel? HD Graphics P630, Maximum on-board graphics card memory: 1.7 GB, On-board graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI. Market segment: Mobile, PCI Express configurations: 1x16, 2x8, 1x8+2x4, Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0. Intel? Turbo Boost Technology 2.0 frequency: 4 GHz
POWERFUL. PRODUCTIVE. PORTABLE.
The Intel? Xeon? processor E3-1500M v6 product family, based on Intel?s newest wave of
14nm processors, delivers the responsive performance, high-speed I/O and enterprise-
grade features that professional power-users demand. With support for Error-Correcting
Code (ECC) memory, workstation application certifications, and Intel? vPro? technology
security and manageability, Intel Xeon processor-based mobile workstations enable the
level of portable business computing that engineers, graphics professionals, and media
creators need and IT requires.
Responsive Performance and High-Speed I/O
The Intel Xeon processor E3-1500M v6 product family leverages the power efficiency of a new microarchitecture for faster performance than previous-generation processors.
Intelligent power management with Intel? Turbo Boost Technology 2.0 dynamically controls performance and power-for cores and graphics-boosting performance when it is needed, and saving energy when it counts. The Intel Xeon processor E3-1500M v6 product family supports four cores and eight threads with Intel? Hyper-Threading Technology
(Intel? HT Technology), enabling powerful, yet sleek, mobile workstations. Thunderbolt? 3 Technology (with 40 Gbps bandwidth) is available on a number of mobile workstation designs alongside ample high-speed I/O, including up to 16 PCIe Gen3 lanes.
Manageability and Stability
Intel? Active Management Technology simplifies PC management and maximizes uptime for increased productivity and lower IT costs. Additionally, Intel? Stable Image Platform Program (SIPP) guarantees no image-breaking hardware/firmware changes and the extended availability of the platform.
Certified Applications
Optimized for a range of independent software vendor (ISV) applications, the Intel Xeon processor E3-1500M v6 product family delivers previously out-of-reach, entry-level workstation performance and visuals to designers, engineers, and media creators.
Workstation-Class Graphics Optimized for Professional Software
Built-in Intel? HD Graphics P630 delivers the hardware-accelerated imagery and media performance that professionals need for vector and bit map visualizations, video transcoding, and ultra-high definition (UHD) display. New enhancements in the processor silicon enable professional software to leverage the added graphics performance for superior portable workstation experiences. The Intel Xeon processor E3-1500M v6 product family enables an entirely new class of powerful, portable, and graphics-accelerated workstations.
Security and Reliability
The Intel Xeon processor E3-1500M v6 product family has been designed to enable hardware-enhanced security, including Intel? Software Guard Extensions (Intel? SGX) that can provide an additional level of hardware-based protection by putting data into a secure container on the platform, and Intel? Memory Protection Extensions (Intel?
MPX) that can help prevent buffer flow attacks. ECC memory support guards your system from potential crashes and changes in data with built-in protection that automatically detects and repairs errors that cause data corruption.
Experience the Best of Windows 10 in a Powerful Mobile Workstation
The premium performance of Intel Xeon processor-powered mobile workstations unleashes massive potential in Windows 10. With accelerated CPU and graphics performance, and enhanced security, manageability, and reliability features, your Windows 10 experience just
gets better. Blazing-fast startup and app switching gets you to work faster, boosting roductivity. And increased efficiency of both the Intel Xeon processor E3-1500M v6 product family and Windows 10 lets you enjoy the freedom to work longer wherever you want.
